VR02 FPV Goggles

Overview

VR02 FPV Goggles

VR02 FPV Goggles - the First-Person-View Goggle with more simpler operation and powerful function, is specially designed for FPV starters.

• With the built-in antennas and structure patented design, the VR02 Goggles is more compact and exquisite, less than 300g lightweight is more comfortable for wearing and carrying.
• VR02 goggle comes with built-in 5.8G 14DBI high-quality antennas, you can receive stable and clear images even for long-range flights.
• With 4.3 inches 800*480px HD high brightness LCD, VR02 Goggles will show you a bright world without warped and blurred images, which is specially tuned for FPV racing or Model airplanes.
• Upgraded the frequency sweep function and the fast frequency auto-search function(only 2.5 seconds), pilots can easily find a band and channel with a stronger signal for a better flight experience.
• The advanced auto-searching function will show you the working frequency on the screen vividly.
• Adopt an ergonomic design with a foam sponge faceplate and a three-sided adjustable headband, this FPV Goggles fits your face and head perfectly.

• BETAFPV VR02 FPV Goggles has a frequency sweep function and a fast frequency auto-search function, it will help pilots find a stronger Band to get a better flight experience.
• The frequency sweep function can display the occupancy status of each channel in the current space so that pilots can fly with a better Band and enhance the flight experience.

BETAFPV Patented Design

With the built-in antennas and the special design of the Goggles lens, the VR02 Goggles is more compact and exquisite, which makes it maintains a small and lightweight body.

Instruction

Power On/Off

Flick to the left to turn off, and to the right to turn on, the screen will light up after a normal boot.

Band+

Short press for Band+ option A, B, E, F, R, L cycle selection.

Search

After powering on, short press the "S" button to enter the sweeping interface. Press and hold the "S" button for 1 second to start the frequency auto-search.

CH+

Short press for CH 1~8 cycles.

Specification

BODY

Dimension: 126x143x86.3mm

Weight: 300g with 2hr 2000mAh battery

Belt: Three-Ways adjustable belt

SCREEN

screen size: 4.3 inch

Screen resolution: 800*480 px

Screen brightness: 300cd/m2

View Angle: 55°

JACK

Type-C Charging

Voltage: 3.7V, the device operating current of 500mA@3.7V

Current: 500mA

BATTERY

Built-in 3.7V/2000mAh high-capacity polymer battery, LED turn on while charging. When charging is completed, the LED will turn off.

Each full charge revive is around 2 hours working time

Package

1 * BETAFPV VR02 FPV Goggles

1 * Adjustable Headband
